美孚力富 SHC 系列
美孚力富 SHC™ 系列潤滑油經過專門設計,可充分滿足嚴苛溫度下應用的潤滑要求。
我們的美孚力富 SHC™ 系列多用途潤滑脂是經過專門設計的高性能合成潤滑脂,可為在嚴苛溫度下應用的設備提供保護。出色的粘性、結構穩定性和耐水性,使其廣泛適用于多種設備和組件。
美孚力富 SHC 系列潤滑脂可提供卓越的抗磨損、防銹和防腐蝕保護,從而幫助:
提高設備運行效率
幫助延長軸承和設備使用壽命
實現長潤滑脂使用壽命
減少維護成本
減少能耗和起動扭矩
延長的補脂周期有助縮短停機時間并降低維護成本
具有防銹、防腐蝕和抗磨損性,有助延長設備壽命
370 余家制造商認可或支持美孚力富 SHC 系列潤滑脂
在嚴苛條件下仍能提供卓越保護,幫助減少維護
美孚力富 SHC™ 系列提供 7 個潤滑油等級。
利用下方的過濾條件縮小您的搜索結果范圍
產品類型
潤滑脂
顯示了 7 款推薦產品,共 7 個產品等級
![]() | Mobilith SHC 007 Mobilith SHC™ 系列潤滑脂是針對極端溫度條件下的各種應用而研發的優質產品。 |
![]() | Mobilith SHC 100 Mobilith SHC™ 系列潤滑脂是針對極端溫度條件下的各種應用而研發的優質產品。 |
![]() | Mobilith SHC 1000 Special Mobilith SHC™ 系列潤滑脂是針對極端溫度條件下的各種應用而研發的優質產品。 |
![]() | Mobilith SHC 1500 Mobilith SHC™ 系列潤滑脂是針對極端溫度條件下的各種應用而研發的優質產品。 |
![]() | Mobilith SHC 220 Mobilith SHC™ 系列潤滑脂是針對極端溫度條件下的各種應用而研發的優質產品。 |
![]() | Mobilith SHC 221 美孚力富 SHC™ 系列潤滑脂是針對極端溫度條件下的各種應用而研發的優質產品。 |
![]() | Mobilith SHC 460 Mobilith SHC™ 系列潤滑脂是針對極端溫度條件下的各種應用而研發的優質產品。 |
Features and Benefits
The Mobil SHC brand of oils and greases are recognized and appreciated around the world for their innovation and outstanding performance. The Mobilith SHC series symbolizes ExxonMobil's continued commitment to using advanced technology to provide outstanding products. A key factor in the development of the Mobilith SHC Series were the close contacts between our scientists and application specialists with key Original Equipment Manufacturers (OEMs) to ensure that our product offerings would provide exceptional performance in the continually evolving industrial equipment designs.
Our work with equipment builders has helped confirm the results from our own laboratory tests showing the exceptional performance of the Mobilith SHC Series lubricants. These benefits include longer grease life, enhanced bearing protection and bearing life, wide temperature range of application, and the potential for improved mechanical efficiency and energy savings.
To combat high thermal exposure of the oil our product formulation scientists chose proprietary synthetic base oils for Mobilith SHC Series oils because of their exceptional thermal/oxidative resistance potential. Our scientists developed a state-of-the-art lithium complex thickener technology and used specific additives to enhance the performance of each grade of the Mobilith SHC Series product family. The Mobilith SHC Series greases offer the following features and benefits:
Features | Advantages and Potential Benefits |
Outstanding high temperature and low temperature performance | Wide application temperature ranges, with excellent protection at high temperatures and low torque, easy start-up at low temperatures |
Excellent protection against wear, rust and corrosion | Reduced downtime and maintenance costs because of reduced wear, rust and corrosion |
Excellent thermal stability and oxidation resistance | Extended service life with longer intervals between relubrication and improved bearing life |
Low traction coefficient | Potential to improve mechanical life and reduced energy consumption |
Includes both high and low viscosity grades | Options for outstanding protection of slow speed, heavily loaded bearings, and options for good low temperature performance |
Outstanding structural stability in the presence of water | Retains excellent grease performance in hostile aqueous environments |
Low volatility | Helps resists viscosity increase at high temperatures to maximize relubrication intervals and bearing life |
Applications
Application Considerations: While Mobilith SHC Series greases are compatible with most mineral oil based products, admixture may detract from their performance. Consequently it is recommended that before changing a system to one of the Mobilith SHC Series, it should be thoroughly cleaned out to achieve the maximum performance benefits. While the Mobilith SHC Series greases share many performance benefits, their applications are best described in terms of each product grade:
Mobilith SHC 100 is an antiwear and extreme pressure grease primarily recommended for higher speed applications such as electric motors, where reduced friction, low wear and long service life are required. It is an NLGI 2 Grade / ISO VG 100 grease with a synthetic base fluid. Its operating temperature range is -40o C* to 150o C.
Mobilith SHC 220 is a multi-purpose, NLGI 2 extreme pressure grease recommended for heavy-duty automotive and industrial applications. It uses an ISO VG 220 synthetic base fluid. Mobilith SHC 220 has a recommended operating temperature range of -40o C* to 150o C.
Mobilith SHC 221 is a multi-purpose, extreme pressure grease recommended for heavy-duty automotive and industrial applications, particularly where centralized grease systems are utilized. It uses an ISO VG 220 synthetic base fluid. Mobilith SHC 221 has a recommended operating temperature range of -40o C to 150o C.
Mobilith SHC 460 is an NLGI 1.5 Grade grease with ISO VG 460 synthetic base fluid and is an extreme pressure grease recommended for tough industrial and marine applications. It provides outstanding bearing protection under heavy loads at low-to-moderate speeds and in applications where water resistance is a critical factor. Mobilith SHC 460 has demonstrated outstanding performance in steel mills, paper mills and marine applications. The recommended operating temperature range is -30o C* to 150oC.
Mobilith SHC 1000 Special is an NLGI 2 Grade grease with ISO VG 1000 synthetic base fluid and strongly fortified with solid lubricants including 11% graphite and 1% molybdenum disulphide for maximum protection of plain or rolling element bearings operating under boundary lubrication regimes. This product is designed to extend bearing life under conditions of extremely slow speeds, sliding contacts, and high temperatures. Mobilith SHC 1000 Special has a recommended operating temperature of -30°C* to 150 °C with appropriate relubrication intervals.
Mobilith SHC 1500 is an NLGI 1.5 Grade / ISO VG 1500 grease with a synthetic base fluid. It is intended for use in plain and rolling element bearings operating at extremely slow speeds, under heavy loads and high temperatures. Mobilith SHC 1500 has a recommended operating temperature range of -30 oC* to 150 oC with appropriate relubrication intervals. Continuous lubrication with Mobilith SHC 1500 has been very effective in prolonging bearing life in a severe roll press application. Mobilith SHC 1500 has also provided excellent performance in rotary kiln roller bearings and in slag transfer rail car bearings.
Mobilith SHC 007 is an NLGI 00 Grade / ISO VG 460 grease with a synthetic base fluid; it has a recommended operating temperature range of -50o C to 150 o C with appropriate relubrication intervals. Its primary uses are in grease filled industrial gear cases subject to high temperatures, where conventional semi fluid greases will not provide acceptable lubricant life and in non-driven heavy-duty truck trailer wheel hubs.
*Low temperature claims based on ASTM D 1478 results vs. maximum limits of 10,000 / 1000 gcm @ startup and 1 hour respectively.
Specifications and Approvals
Mobilith SHC Series meets or exceeds the requirements of: | 100 | 220 | 221 | 460 | 1000 Special | 1500 | 007 |
DIN 51825: (2004-06) | KPHC 2N-40 | KPHC 2N-30 | - | KPHC 1-2N-40 | KPFHC 2N-30 | KPHC 1-2N-30 | - |
DIN 51826: (2005-01) | - | - | - | - | - | - | GPHC 00K-30 |
Mobilith SHC Series has the following builder approvals: | 100 | 220 | 221 | 460 | 1000 Special | 1500 | 007 |
AAR-942* | X | - | X | - | - | - | - |
Fives Cincinnati | P-73 | P-64 | P-81 |
*For product only supplied to North American Railroads
Typical Properties
Mobilith SHC Series | 100 | 220 | 221 | 460 | 1000 Special | 1500 | 007 |
NLGI Grade | 2 | 2 | 1 | 1.5 | 2 | 1.5 | 00 |
Thickener Type | Lithium Complex | Lithium Complex | Lithium Complex | Lithium Complex | Lithium Complex | Lithium Complex | Lithium Complex |
Color, Visual | Red | Red | Light Tan | Red | Grey Black | Red | Red |
Penetration, Worked, 25oC, ASTM D 217 | 280 | 280 | 325 | 305 | 280 | 305 | 415 |
Dropping Point, oC, ASTM D 2265 | 265 | 265 | 265 | 265 | 265 | 265 | - |
Viscosity of Oil, ASTM D 445 cSt @ 40oC | 100 | 220 | 220 | 460 | 1000 | 1500 | 460 |
4-Ball Weld, ASTM D 2596, Load, Kg | 250 | 250 | 250 | 250 | 620 | 250 | 250 |
Water Washout, ASTM D 1264, 79 oC, % Wt. Loss | 6 | 3 | 4 | 3 | 2.6 | 2.5 | - |
Rust Protection, ASTM D 6138, Distilled Water | 0,0 | 0,0 | 0,0 | 0,0 | 0,0 | 0,0 | - |
Corrosion Protection, ASTM D 1743, Rating | Pass | Pass | Pass | Pass | Pass | Pass | - |
4-Ball Wear, ASTM D 2266, Scar, mm | 0.50 | 0.50 | 0.50 | 0.50 | 0.50 | 0.50 | 0.50 |
Low Temperature Torque, ASTM D 1478, Torque @ Startup/1 Hour in gcm and Test To | 9520/2199 @ -50 oC | 4361/836 @ -40 oC | ---- | 9060/2944 @ -40 oC | ---- | 1874/‹1000 @ -20 oC | ---- |
U.S. Mobility, AM-S 1390, -18 oC, gms/min | 20.0 | 11.0 | ---- | 5.0 | ---- | 3.0 | ---- |
Health and Safety
Based on available information, this product is not expected to produce adverse effects on health when used for the intended application and the recommendations provided in the Material Safety Data Sheet (MSDS) are followed. MSDS's are available upon request through your sales contract office, or via the Internet. This product should not be used for purposes other than its intended use. If disposing of used product, take care to protect the environment.
